Detailed Description
This 6-way male receptacle from Amp Sine is durable and functional with size 16 pin contacts. Operating at 13A this blue receptacle is powerful and protected with an IP67 rated reduced diameter seal. Mates with AT06-6S Plug.
Product information
| Manufacturer: | Amphenol Sine Systems |
| Color: | Blue |
| Gender: | Male |
| Max Amperage: | 13A |
| Temperature Rating Range: | -55°C to 125° C |
| Wire Gauge: | 16-22AWG |
| Degree of Protection: | IP67 |
| Contact Size: | 16 |
| Number of Cavities: | 6 |
| Wire Range: | 14-20AWG |
| Contact Type (Pin/Socket/Plug): | Pin |
| Seal Diameter: | 1.35mm - 3.05mm |
| Seal Material: | Silicone Elastomer |
| Housing Material: | Thermoplastic |
| Mating Cycle Durability: | >100 |
| Insulation Resistance: | 1000 Megaohms at 25°C |
| Item Weight (kg): | 0.01814369 |
