Detailed Description
This 8-position female plug from Amp Sine is durable and functional with a wide thread and size 12 socket contacts. Operating at 25A this plug is powerful and protected with an IP67 rated standard seal. Mates with AHDP04-18-08P.
Product information
| Manufacturer: | Amphenol Sine Systems |
| Color: | Black |
| Gender: | Female |
| Max Amperage: | 25A |
| Wire Gauge: | 10-14AWG |
| Degree of Protection: | IP67 / IP69K |
| Contact Size: | 12 |
| Number of Cavities: | 8 |
| Wire Range: | 10-14AWG |
| Contact Type (Pin/Socket/Plug): | Socket |
| Seal Diameter: | 3.43 mm - 4.32 mm |
| Rear Seal Type: | Normal |
| Seal Color: | Red |
| Seal Material: | Silicone Rubber |
| Housing Material: | Thermoplastic |
| Mating Cycle Durability: | >100 |
| Insulation Resistance: | 1000 Megaohm min at 25°C |
| Item Weight (kg): | 0.05 |
| Group Type: | Circular Connectors |
